STS 1-Liter DTF Ink Cartridges – CMYK & White • USA-Made • Designed for the STS XPD-924D DTF Printer
STS
The STS 1-Liter DTF Ink Pouches deliver the same USA-made, degassed, OEKO-TEX certified ink as the STS 500ml cartridges — in a high-volume format for production shops running the XPD-924D at full capacity. CMYK channels come as 1-Liter pouches; White comes in a 900ml pouch due to higher pigment density. Fewer cartridge swaps, lower cost per ml, and the same batch-to-batch color consistency STS is known for.
🆕 Free Shipping Over $200|
📞 (512) 454-0505
Price range: $127.14 through $508.56
Description
More Ink, Less Downtime — The 1-Liter Upgrade for High-Volume Shops
If you are running the STS XPD-924D at production capacity — 100+ linear feet of film per day — the 500ml cartridge format means frequent swap-outs that interrupt your workflow. The STS 1-Liter pouches solve that by doubling your CMYK capacity in a single load. Same ink, same quality, same batch-to-batch consistency — just a larger format that keeps your machine printing longer between interruptions.
500ml Cartridge vs. 1-Liter Pouch — Which Is Right for You?
| Factor | 1-Liter Pouch | 500ml Cartridge |
|---|---|---|
| Volume (CMYK) | 1,000 ml | 500 ml |
| Volume (White) | 900 ml | 500 ml |
| Best for | High-volume production shops | Medium-volume / starter shops |
| Cartridge swap frequency | Less frequent | More frequent |
| Cost per mL | Lower | Higher |
| Ink formula | Identical STS XPD2 formula | Identical STS XPD2 formula |
Ink Consumption Planning Guide
Expect 2–3 White pouches for every CMYK pouch consumed. Dark garment runs use even more White.
White channel ships as 900ml (not 1 Liter) due to the higher pigment density of white DTF ink. Never let White run completely empty — the XPD-924D’s circulation system can introduce air into the lines if a bag empties mid-job.
Heat Press Application Guide
| Fabric Type | Temp | Dwell Time | Pressure | Peel | Notes |
|---|---|---|---|---|---|
| 100% Cotton | 300–320°F | 12–15 sec | Medium-Firm | Cold | Best adhesion; most forgiving substrate for DTF. |
| 50/50 Poly-Cotton | 305–315°F | 12–15 sec | Medium-Firm | Cold | Most popular DTF substrate; consistent results. |
| 100% Polyester | 275–295°F | 10–12 sec | Light-Medium | Cold | Lower temp prevents dye migration. Always test. |
| Athletic/Performance | 275–295°F | 10–12 sec | Light | Warm | DTF excels here — stretches without cracking. |
| Nylon | 265–285°F | 10–12 sec | Light | Cold | Heat-sensitive — test on your specific nylon first. |
| Denim / Canvas | 305–315°F | 15–18 sec | Firm | Cold | Heavier weave needs longer dwell for full bond. |
Always press the garment for 3–5 seconds to remove moisture before applying the transfer. Moisture is the #1 cause of DTF transfer adhesion failure.
Fabric Compatibility
| Fabric / Substrate | Compatibility | Pre-Treatment | Notes |
|---|---|---|---|
| 100% Cotton | Excellent | None | Best adhesion; ideal starting point |
| 50/50 Poly-Cotton | Excellent | None | Most popular DTF substrate |
| 100% Polyester | Excellent | None | Lower press temp; test for dye migration |
| Athletic/Performance | Excellent | None | Stretches and recovers without cracking |
| Tri-Blend | Very Good | None | Soft feel; test wash recommended |
| Nylon | Good | None | Lower temp; always test specific type |
| Denim / Canvas | Very Good | None | Longer press time for thick weave |
| Silk / Delicates | Not Recommended | — | Heat press temps damage delicate fibers |
Everything Else Your XPD-924D Needs
The production 24″ dual-head DTF printer these 1-liter cartridges were made for.
Matched roll film for the XPD-924D. Double-sided matte, hot or cold peel, 328 ft.
Automatic 24″ IR powder shaker — the finishing system for the XPD-924D line.
Hot-melt TPU adhesive powder. Bonds transfers to any fabric after curing.
Technical Specifications
STS 1-Liter DTF Ink Pouches — Technical Specifications
| Specification | Detail |
|---|---|
| Ink Type | Direct-to-Film (DTF) — Pigment-Based |
| Volume | 1 Liter (CMYK) / 900ml (White) |
| Available Channels | Cyan, Magenta, Yellow, Black (CMYK) and White |
| Compatible Printer | STS XPD-924D 24″ DTF Printer |
| Compatible Printhead | Epson AccuFine HD |
| Format | Pouch/bag refill — requires compatible reservoir or bag-in-box system |
| Pigment Technology | Encapsulated resin + nano-pigment |
| Degassing | Yes — STS proprietary micro-bubble elimination |
| Washability | AATCC 61 Method 2A |
| Toxicity | Non-toxic, environmentally friendly |
| Certification | OEKO-TEX ECO Passport |
| Origin | Made in USA |
| Shelf Life | 1 year from manufacture date |
| White Volume Note | White channel ships as 900ml (not 1L) due to higher pigment density |
Technical Sheets / Safety Data Sheets / Documents
FREQUENTLY ASKED QUESTIONS
Frequently Asked Questions — STS 1-Liter DTF Ink Pouches
Yes — identical formula, same degassed encapsulated nano-pigment ink, same OEKO-TEX ECO Passport certification, same batch-to-batch color consistency. The only difference is volume and packaging format.
White DTF ink uses titanium dioxide pigment at a much higher concentration than CMYK inks. The higher pigment loading means slightly more mass per volume, and 900ml is the standard commercial format for this ink type. Functionally, 900ml White still significantly outlasts a 500ml cartridge.
These 1-Liter pouch inks are formulated specifically for the STS XPD-924D and its AccuFine HD printhead system. They are not interchangeable with the 220ml cartridge inks for the XPD-724 or bottle-format inks for Epson-based desktop systems. Call (512) 454-0505 if you are unsure which ink your printer needs.
Store in a cool, dry location away from direct sunlight. Do not freeze. Shelf life is 1 year from manufacture date. Once installed in the printer system, follow STS’s recommended maintenance schedule.
Yes — STS printhead warranty eligibility applies to any official STS ink format (500ml, 1L, cleaning solution) as long as you complete the STS ink registration process. Contact STS or ask River City Supply for the warranty registration link.
