Vastex C-100 Manual Screen Coating Rack – Compact, Adjustable Emulsion Coating Solution

Name: Vastex C-100 Manual Screen Coating Rack – Compact, Adjustable Emulsion Coating Solution - River City Supply
SKU: VAS C-100
Price: 419.00 USD
Availability: InStock

Vastex

The Vastex C-100 Manual Screen Coating Rack holds your screen firmly at the coating angle so both hands are free to run the scoop coater — for smooth, even, repeatable coats without screens slipping or dropping. Tool-free height and length adjustments fit screens from 23″ to 36″, and the wall-mount design saves floor space. An affordable, no-electricity way to get a consistent emulsion coat every time. Made by Vastex from rigid carbon steel.

Hands-free coating
Holds the screen firmly — no slipping

Even, repeatable coats
Screen held at the right angle every time

Tool-free adjustment
Quick height & screen-length settings

Fits 23″–36″ screens
Wood, aluminum & retensionable frames

Wall-mount, space-saving
Optional freestanding or wheeled stand

Rigid carbon steel
Baked-on finish, built to last

Both hands free, every screen coated the same. The affordable way to coat evenly without screens slipping or dropping. Questions? Call 512-454-0505.

$419.00

As low as $10 per month with ACG Equipment Financing

SKU: VAS C-100 Categories: Screen Coating Machines for Screen Printing, Screen Printing Equipment Tags: manual emulsion coater, manual screen coating rack, scoop coater rack screen printing, screen printing emulsion coating rack, screen room coating rack, space saving screen coating rack, Vastex C-100 screen coating rack, Vastex screen coating equipment, Vastex screen room equipment, wall mount screen coating rack

Description

Vastex C-100 — Compact, Adjustable, Hands-Free Coating

Great prints start with an even coat of emulsion — and that starts with holding the screen still. The Vastex C-100 Manual Screen Coating Rack clamps your screen firmly at the coating angle so you can run the scoop coater with both hands, laying down a smooth, uniform coat every time. No more balancing a screen on your knee or against a table, no more slips or drips. It’s the simple, affordable way to coat consistently — and it mounts on the wall to save floor space.

Why You Need a Coating Rack

Coating a screen freehand is awkward and inconsistent. When you’re also holding the screen, it shifts and tips as you pull the coater — so the emulsion goes on uneven, with thin spots, heavy edges, drips and re-coats. That variability follows the screen all the way to press: exposure times drift, fine detail suffers, and stencils break down early. The C-100 fixes the root cause by holding the screen firmly in place, freeing both hands for one smooth, controlled pass. You get more even, repeatable coats, less wasted emulsion, less mess — and a faster, cleaner screen room.

Both hands on the coater

The rack holds the screen so you don’t have to. Two free hands mean smoother, straighter, more even scoop-coater passes — and no fumbling or dropped screens.

Repeatable results

A screen held at a consistent angle gets a consistent coat — the foundation of reliable exposures and sharp, clean prints, screen after screen.

Tool-free adjustments

Quick height and screen-length adjustments with no tools — set it for your frames in seconds and switch sizes on the fly.

Fits your screens

Handles all popular frame lengths from 23″ to 36″ — wood, aluminum or retensionable — up to 11 lb, with an optional spring-loaded clamp for extra stability.

Saves floor space

A wall-mount design with hardware included keeps your coating station off the floor. Prefer to roll it around? Add the optional freestanding or wheeled stand.

Built to last

Rigid carbon steel with a durable baked-on finish, plus a built-in shelf for your scoop coater. Lightweight at 20 lb or less and ships via UPS.

Why Buy From River City Supply?

Real screen printers. Real support. Genuine equipment.

Real printers on staff

Talk to people who run this gear — we’ll help you spec, install and dial in coating for your emulsions. Call (512) 454-0505.

Genuine Vastex, full warranty

Authentic, USA-made Vastex equipment backed by the manufacturer warranty.

Fast shipping + 1-hour pickup

Ships quick via UPS, and in-stock items are ready for in-store pickup within an hour in Central Texas.

Financing available

Spread the cost of your equipment — apply for equipment financing, or ask us how.

Everything under one roof

Emulsion, screens, exposure and curing — outfit your whole pre-press from one supplier.

Support after the sale

Family-run and here Monday–Friday, 9–5, long after your order ships.

Call (512) 454-0505

What you’ll need with it

You supply the scoop coater and emulsion (size the coater to your screens). Pair the C-100 with quality screens & mesh, a drying cabinet to dry coated screens dust-free, and an exposure unit to burn them.

Want hands-free and motorized?

Coating a lot of screens? Step up to the Vastex C-1000 semi-automatic coater, which lowers the screen with a foot pedal at a set, repeatable speed. See all coating & pre-press equipment.

Questions? Talk to a printer

Not sure which coater or scoop-coater width fits your screens? Call or message us — we run this gear and we’ll help you set up your screen room right.

Call 512-454-0505

Apply for financing

Spread the cost of your pre-press equipment with simple financing.

Explore Financing

Technical Specifications

Vastex C-100 — Technical Specifications

Type	Manual screen coating rack (holds the screen; you coat by hand)
Operation	Clamps the screen firmly at the coating angle so both hands are free to run the scoop coater — no slipping or dropping
Screen lengths	Fits all popular sizes from 23″ to 36″ (23″, 28″, 31″, 36″)
Adjustments	Tool-free quick height and screen-length adjustment
Frame weight capacity	Up to 11 lb (5 kg)
Compatible frames	Wood, aluminum and retensionable frames
Clamp	Optional spring-loaded clamp for extra frame stability
Scoop-coater shelf	Built-in shelf to hold your scoop coater
Mounting	Wall-mount design with hardware included; optional freestanding or wheeled stand
Construction	Rigid carbon steel with a durable baked-on finish
Rack weight	20 lb (9 kg) or less — ships via UPS
Origin	Made by Vastex
Best for	Hobbyists, startups, schools and production shops

Pairs Well With

Emulsions & Stencil
Coat your screens Screens, Frames & Mesh
Wood, aluminum, retensionable Drying Cabinet
Dry coated screens dust-free Exposure Units
Burn sharp, repeatable stencils Step up: Vastex C-1000
Semi-automatic, foot-pedal coater Financing
Spread the cost

Technical Sheets / Safety Data Sheets / Documents

Vastex C-100 Brochure & Specifications

Vastex C-100 Screen Rack Manual

FREQUENTLY ASKED QUESTIONS

Vastex C-100 — Frequently Asked Questions

What is the Vastex C-100?

It’s a manual screen coating rack. It holds your screen firmly at the coating angle so both hands are free to run the scoop coater, giving you smooth, even, repeatable coats of emulsion without screens slipping or dropping.

How does a coating rack improve my screens?

Coating freehand is inconsistent — the screen shifts while you pull the coater, so emulsion goes on unevenly. By holding the screen still, the C-100 lets you make one smooth, controlled pass for a consistent coat, which means more reliable exposures and sharper prints.

What screen sizes does it fit?

All popular frame lengths from 23″ to 36″ (23″, 28″, 31″ and 36″), in wood, aluminum or retensionable frames up to 11 lb.

Is it hands-free?

Yes — the whole point of the rack is to hold the screen so both of your hands are free for the scoop coater. An optional spring-loaded clamp adds extra frame stability.

Does it mount to a wall, or is there a stand?

It’s a wall-mount design and includes the mounting hardware to save floor space. An optional freestanding stand — with or without wheels — is available if you’d rather have it mobile.

How is the C-100 different from the C-1000?

The C-100 is the manual rack — it holds the screen while you coat by hand. The C-1000 is semi-automatic: a foot pedal lowers the screen at a set, motor-controlled speed for even more repeatability and higher volume. Both give you consistent coats; the C-100 is the affordable, no-electricity option.

Do I need to buy emulsion and a scoop coater separately?

Yes — you supply the emulsion and a scoop coater sized to your screens. We can help you match the right coater width and emulsion to your work.

What’s it made of and how does it ship?

Rigid carbon steel with a durable baked-on finish, with a built-in scoop-coater shelf. It weighs 20 lb or less and ships via UPS.

Is financing available?

Yes — you can apply for equipment financing to spread the cost of your pre-press equipment. Call (512) 454-0505 and we’ll help you get set up.
