STS Inks Replacement Ink for Mimaki LUS-150 UV Curable – 1 Liter High-Performance UV Ink
STS Inks
STS Replacement Ink for Mimaki LUS-150 UV (1 Liter) — flexible UV-LED ink for Mimaki JFX200, JFX500, UJV55-320, UJF-7151, and UJF-6042 MkII series. 1.5× the flexibility of conventional UV ink. Plug & Play from OEM. USA-made.
Price range: $112.86 through $1,015.74
Description
STS Replacement Ink for Mimaki LUS-150 UV Curable (1 Liter) — Flexible UV-LED UV Curable Ink
The STS LUS-150 (1-Liter Bottle) is a flexible UV-LED ink replacement for Mimaki’s mid-generation production flatbeds and roll-to-roll UV printers. LUS-150 offers 1.5× the flexibility of conventional UV inks, making it resistant to post-curing cracking during routing or cutting. It is also used as the process ink for JFX200 setups that combine LUS-150 with LH-100 clear. Plug & Play from OEM LUS-150 — no line flush or color profile changes required.
Key Features
Cures immediately under UV-LED light — no drying time, no smearing, ready for finishing the moment it leaves the printer.
Manufactured by STS in the USA and drop shipped directly from Florida for guaranteed freshness.
STS UV inks are a virtual match to OEM. No need to flush lines or update color profiles when switching from OEM.
Virtually scent-free during printing — suitable for open shop environments without special ventilation.
Scratch, fade, and weather resistant. Rated for outdoor durability without lamination on most substrates.
Formulated for vivid color accuracy across the full color set — matching OEM color profiles precisely.
Printer Compatibility
| Printer Model | Series | Notes |
|---|---|---|
| Mimaki JFX200-2513 / JFX200-2513 EX | JFX200 Series | Large-format UV-LED flatbed — 2.5×1.3m |
| Mimaki JFX200-2531 | JFX200 Series | Large-format UV-LED flatbed — 2.5×3.1m |
| Mimaki JFX500-2131 | JFX500 Series | High-speed UV-LED flatbed — 2.1×3.1m |
| Mimaki UJV55-320 | UJV55 Series | 320cm wide roll-to-roll UV-LED printer |
| Mimaki UJF-7151 plus / plus II | UJF Series | Tabletop UV-LED flatbed — 710×510mm |
| Mimaki UJF-6042 MkII / MkII e | UJF Series | Tabletop UV-LED flatbed — 600×420mm |
Substrate Compatibility
| Substrate | Type | Applications |
|---|---|---|
| PVC / Vinyl Banner | Flexible vinyl, banner material | Indoor/outdoor signage, trade show displays |
| Adhesive Vinyl | Pressure-sensitive vinyl | Decals, vehicle graphics, labels |
| Rigid PVC | Foamboard, Sintra, Coroplast | Signs, POP displays, menu boards |
| Acrylic | Cast and extruded acrylic | Backlit displays, dimensional signage |
| Aluminum / Metal | Aluminum composite, aluminum sheet | Outdoor signs, architectural graphics |
| Glass | Tempered and standard glass | Retail window graphics, architectural |
| Polyester Film | Polyester / backlit film | Backlit displays, light box inserts |
| Wood | Plywood, MDF, finished wood | Décor, POS, specialty signage |
Watch: STS Inks Introduction
Also See — STS Mimaki UV Inks
600ml flexible UV — JFX-1615plus/1631plus, UJF-3042/6042, UJV-160.
Technical Specifications
Technical Specifications
| Specification | Detail |
|---|---|
| Product | STS Replacement Ink for Mimaki LUS-150 UV Curable (1 Liter) |
| SKU | MIM.UV.LUS150 |
| OEM Code | LUS-150 / LUS15-X-BA |
| Volume | 1,000ml |
| Format | 1-Liter Bottle |
| UV Ink Type | Flexible UV-LED |
| Colors | Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, White |
| Cure | UV-LED instant cure |
| Origin | Made in USA — STS Boca Raton, FL |
| Ships | Drop ships fresh from STS Florida |
| Returns | No returns |
Technical Sheets / Safety Data Sheets / Documents
FREQUENTLY ASKED QUESTIONS
FAQ — STS Replacement Ink for Mimaki LUS-150 UV Curable (1 Liter)
LUS-150 is confirmed for: JFX200-2513, JFX200-2513 EX, JFX200-2531, JFX500-2131, UJV55-320, UJF-7151 plus, UJF-7151 plus II, UJF-6042 MkII, and UJF-6042 MkII e. If you have a UCJV300 series or older JFX-1615plus, check whether your printer uses LUS-170 or LF-140 instead.
LUS-120 is the most flexible and lowest-cost Mimaki UV ink, ideal for roll-to-roll banners and vinyl. LUS-150 offers balanced flexibility and adhesion — good for both rigid and flexible substrates, including routed pieces. LUS-170 is the premium flexible ink for the UCJV300 series, designed for vehicle wraps and high-stretch applications. They are not interchangeable between different printer generations.
Yes. On JFX200 flatbed setups, LH-100 clear ink can be used in combination with LUS-150 process colors for gloss or texture effects. LUS-150 does not include its own clear channel.
Yes — STS UV inks are a virtual OEM match. No flush or profile changes needed when switching from OEM. Simply swap the cartridge and continue printing.
UV-curable inks adhere to rigid and flexible substrates including PVC, vinyl, adhesive vinyl, acrylic, aluminum, glass, polyester film, and wood. Always run an adhesion test on new substrates before production.
No. All STS ink products are non-returnable. Confirm your printer model and OEM ink code before ordering. Call (512) 454-0505 if unsure.
STS UV inks are rated for outdoor durability without lamination on most substrates. For vehicle wraps and high-UV-exposure applications, lamination is always recommended for maximum longevity.
All STS UV inks are manufactured in the USA by STS in Boca Raton, FL. Orders drop ship directly from Florida for guaranteed freshness.
